دیتاشیت RHRP8120-F102
مشخصات دیتاشیت
| نام دیتاشیت | MBR1080, 1090, 10100 |
|---|---|
| حجم فایل | 130.925 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت MBR1080, 1090, 10100 |
MBR1080, 1090, 10100 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: onsemi RHRP8120-F102
- Reverse Voltage (Vr): 1200V
- Operating Temperature: -65°C~+175°C
- Forward Voltage (Vf@If): 3.2V@8A
- Reverse Leakage Current: 100uA@1200V
- Average Rectified Current (Io): 8A
- Package: TO-220-2
- Manufacturer: onsemi
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 1200V
- Current - Average Rectified (Io): 8A
- Voltage - Forward (Vf) (Max) @ If: 3.2V @ 8A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 70ns
- Current - Reverse Leakage @ Vr: 100µA @ 1200V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: TO-220-2
- Supplier Device Package: TO-220-2
- Operating Temperature - Junction: -65°C ~ 175°C
- Base Part Number: RHRP81
- detail: Diode Standard 1200V 8A Through Hole TO-220-2
