دیتاشیت MUR3060WTG
مشخصات دیتاشیت
| نام دیتاشیت |
MUR3020, 60WT
|
| حجم فایل |
78.818
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Switching Diode
-
Datasheet:
onsemi MUR3060WTG
-
Power Dissipation:
-
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
600V
-
Operating Temperature:
-65°C~+175°C@(Tj)
-
Forward Voltage (Vf@If):
1.7V@15A
-
Reverse Leakage Current:
10uA@400V
-
Reverse Recovery Time (trr):
60ns
-
Average Rectified Current (Io):
15A
-
Package:
TO-247
-
Manufacturer:
onsemi
-
Series:
SWITCHMODE™
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
600V
-
Current - Average Rectified (Io) (per Diode):
15A
-
Voltage - Forward (Vf) (Max) @ If:
1.7V @ 15A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
10µA @ 600V
-
Operating Temperature - Junction:
-65°C ~ 175°C
-
Mounting Type:
Through Hole
-
Package / Case:
TO-247-3
-
Supplier Device Package:
TO-247
-
Base Part Number:
MUR30
-
detail:
Diode Array 1 Pair Common Cathode Standard 600V 15A Through Hole TO-247-3
