BAS16DXV6T1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
BAS16DXV6T1G
|
|
حجم فایل
|
73.776
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Switching Diode
-
Datasheet:
onsemi BAS16DXV6T1G
-
Power Dissipation:
500mW
-
Diode Configuration:
2 Independent
-
Reverse Voltage (Vr):
75V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
1.25V@150mA
-
Reverse Leakage Current:
1uA@100V
-
Reverse Recovery Time (trr):
6ns
-
Average Rectified Current (Io):
200mA
-
Package:
SOT-563
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
75V
-
Current - Average Rectified (Io) (per Diode):
200mA (DC)
-
Voltage - Forward (Vf) (Max) @ If:
1.25V @ 150mA
-
Speed:
Small Signal =< 200mA (Io), Any Speed
-
Current - Reverse Leakage @ Vr:
1µA @ 75V
-
Operating Temperature - Junction:
-55°C ~ 150°C
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-563, SOT-666
-
Supplier Device Package:
SOT-563
-
Base Part Number:
BAS16
-
detail:
Diode Array 2 Independent Standard 75V 200mA (DC) Surface Mount SOT-563, SOT-666
