- دیتاشیت SZESD7371HT1G
SZESD7371HT1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SZESD7371HT1G |
|---|---|
| حجم فایل | 90.494 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 9 |
دانلود دیتاشیت SZESD7371HT1G |
دانلود دیتاشیت |
|---|
سایر مستندات
ESD7371, SZESD7371 Series 8 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Polarity: Unidirectional
- Datasheet: onsemi SZESD7371HT1G
- Clamping Voltage@Ipp: -
- Operating Temperature: -55°C~+150°C@(Tj)
- Breakdown Voltage (VBR): 7V
- Peak Pulse Power(Ppp)@8/20us: -
- Junction Capacitance(Cj)@1MHz: 0.43pF@1MHz
- Reverse Stand-Off Voltage (Vrwm): 5.3V
- Package: SOD-323
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Unidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 5.3V (Max)
- Voltage - Breakdown (Min): 7V
- Voltage - Clamping (Max) @ Ipp: -
- Current - Peak Pulse (10/1000µs): -
- Power - Peak Pulse: -
- Power Line Protection: No
- Applications: Automotive, RF Antenna
- Capacitance @ Frequency: 0.43pF @ 1MHz
- Mounting Type: Surface Mount
- Package / Case: SC-76, SOD-323
- Supplier Device Package: SOD-323
- Base Part Number: SZESD7
- detail: Clamp Ipp Tvs Diode Surface Mount SOD-323
