MC74VHC1G05DFT1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MC74VHC1G05DFT1G
|
|
حجم فایل
|
75.727
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
14
|
مشخصات فنی
-
RoHS:
true
-
Series:
74VHC
-
Category:
Logic ICs/Inverters
-
Datasheet:
onsemi MC74VHC1G05DFT1G
-
Sink Current:
8mA
-
Number of Inputs:
1
-
Number of Circuits:
1
-
Supply Current (Max):
1uA
-
Low level range (VIL):
0.5V~1.65V
-
Max Propagation Delay:
7.5ns@5V,50pF
-
Operating Temperature:
-55°C~+125°C
-
High level range (VIH):
1.5V~3.85V
-
Supply Voltage(Single):
2V~5.5V
-
Package:
SC-70-5
-
Manufacturer:
onsemi
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Logic Type:
Inverter
-
Features:
Open Drain
-
Voltage - Supply:
2V ~ 5.5V
-
Current - Quiescent (Max):
1µA
-
Current - Output High, Low:
-, 8mA
-
Logic Level - Low:
0.5V ~ 1.65V
-
Logic Level - High:
1.5V ~ 3.85V
-
Max Propagation Delay @ V, Max CL:
7.5ns @ 5V, 50pF
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-88A (SC-70-5/SOT-353)
-
Package / Case:
5-TSSOP, SC-70-5, SOT-353
-
Base Part Number:
MC74VHC1G05
-
detail:
Inverter IC 1 Channel Open Drain SC-88A (SC-70-5/SOT-353)
