دیتاشیت RS1GFA
مشخصات دیتاشیت
| نام دیتاشیت | RS1AFA, NRVHPRS1AFA Series |
|---|---|
| حجم فایل | 109.528 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت RS1AFA, NRVHPRS1AFA Series |
RS1AFA, NRVHPRS1AFA Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: onsemi RS1GFA
- Reverse Voltage (Vr): 400V
- Operating Temperature: -55°C~+150°C
- Forward Voltage (Vf@If): 1.3V@800mA
- Reverse Leakage Current: 5uA@400V
- Reverse Recovery Time (trr): 250ns
- Average Rectified Current (Io): 800mA
- Package: SOD-123FA
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 400V
- Current - Average Rectified (Io): 800mA
- Voltage - Forward (Vf) (Max) @ If: 1.3V @ 800mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 5µA @ 400V
- Capacitance @ Vr, F: 10pF @ 4V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: SOD-123W
- Supplier Device Package: SOD-123FA
- Operating Temperature - Junction: -55°C ~ 150°C
- Base Part Number: RS1
- detail: Diode Standard 400V 800mA Surface Mount SOD-123FA
