SZESD7361XV2T1G دیتاشیت

SZESD7361XV2T1G

مشخصات دیتاشیت

نام دیتاشیت SZESD7361XV2T1G
حجم فایل 74.49 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت SZESD7361XV2T1G

دانلود دیتاشیت

سایر مستندات

ESD7361, SZESD7361 9 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: onsemi SZESD7361XV2T1G
  • Number of Lines: 1
  • Clamping Voltage@Ipp: 34V
  • Operating Temperature: -55°C~+125°C@(Tj)
  • Breakdown Voltage (VBR): 16.5V
  • Peak Pulse Power(Ppp)@8/20us: -
  • Junction Capacitance(Cj)@1MHz: 0.55pF@1MHz
  • Reverse Stand-Off Voltage (Vrwm): 5V
  • Package: SOD-523
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 5V
  • Voltage - Breakdown (Min): 16.5V
  • Voltage - Clamping (Max) @ Ipp: 34V (Typ)
  • Current - Peak Pulse (10/1000µs): 16A (100ns)
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 0.55pF @ 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: SC-79, SOD-523
  • Supplier Device Package: SOD-523
  • Base Part Number: ESD73
  • detail: 34V (Typ) Clamp 16A (100ns) Ipp Tvs Diode Surface Mount SOD-523
