دیتاشیت 2SD1048-7-TB-E
مشخصات دیتاشیت
| نام دیتاشیت |
2SB815/2SD1048
|
| حجم فایل |
186.552
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi 2SD1048-7-TB-E
-
Transistor Type:
NPN
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
700mA
-
Power Dissipation (Pd):
200mW
-
Transition Frequency (fT):
250MHz
-
DC Current Gain (hFE@Ic,Vce):
200@50mA,2V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
15V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
300mV@100mA,10mA
-
Package:
SOT-23
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
700mA
-
Voltage - Collector Emitter Breakdown (Max):
15V
-
Vce Saturation (Max) @ Ib, Ic:
80mV @ 10mA, 100mA
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
200 @ 50mA, 2V
-
Power - Max:
200mW
-
Frequency - Transition:
250MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
3-CP
-
Base Part Number:
2SD1048
-
detail:
Bipolar (BJT) Transistor NPN 15V 700mA 250MHz 200mW Surface Mount 3-CP
