دیتاشیت CPH6445-TL-W
مشخصات دیتاشیت
| نام دیتاشیت |
CPH6445
|
| حجم فایل |
1072.451
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
60V
-
Current - Continuous Drain (Id) @ 25°C:
3.5A (Ta)
-
Drive Voltage (Max Rds On, Min Rds On):
4V, 10V
-
Rds On (Max) @ Id, Vgs:
117mOhm @ 1.5A, 10V
-
Vgs(th) (Max) @ Id:
-
-
Gate Charge (Qg) (Max) @ Vgs:
6.8nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
310pF @ 20V
-
FET Feature:
-
-
Power Dissipation (Max):
1.6W (Ta)
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
6-CPH
-
Package / Case:
SOT-23-6
-
Base Part Number:
CPH644
-
detail:
N-Channel 60V 3.5A (Ta) 1.6W (Ta) Surface Mount 6-CPH
