AT-42086-TR1G Datasheet
Datasheet specifications
| Datasheet's name | AT-42086 |
|---|---|
| File size | 69.115 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet AT-42086 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Transistor Type: NPN
- Voltage - Collector Emitter Breakdown (Max): 12V
- Frequency - Transition: 8GHz
- Noise Figure (dB Typ @ f): 1.9dB ~ 3.5dB @ 2GHz ~ 4GHz
- Gain: 9dB ~ 13dB
- Power - Max: 500mW
- DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 35mA, 8V
- Current - Collector (Ic) (Max): 80mA
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: SOT-86
- Supplier Device Package: 86 Plastic
- Base Part Number: AT42086
- detail: RF Transistor NPN 12V 80mA 8GHz 500mW Surface Mount 86 Plastic
