MCH3375-TL-W دیتاشیت

MCH3375-TL-W

مشخصات دیتاشیت

نام دیتاشیت MCH3375-TL-W
حجم فایل 457.541 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

مشاهده دیتاشیت MCH3375-TL-W

دانلود دیتاشیت

سایر مستندات

MCH3375 5 pages

مشخصات فنی

  • RoHS: true
  • Type: P Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Power Dissipation (Pd): 800mW
  • Drain Source Voltage (Vdss): 30V
  • Continuous Drain Current (Id): 1.6A
  • Gate Threshold Voltage (Vgs(th)@Id): 2.6V@1mA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 295mΩ@10V,800mA
  • Package: SC-70FL(MCPH-3)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 30V
  • Current - Continuous Drain (Id) @ 25°C: 1.6A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 4V, 10V
  • Rds On (Max) @ Id, Vgs: 295mOhm @ 800mA, 10V
  • Vgs(th) (Max) @ Id: 2.6V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 2.2nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 82pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 800mW (Ta)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SC-70FL/MCPH3
  • Package / Case: 3-SMD, Flat Lead
  • Base Part Number: MCH33
  • detail: P-Channel 30V 1.6A (Ta) 800mW (Ta) Surface Mount SC-70FL/MCPH3
