MCH3478-TL-W Datasheet

MCH3478

Datasheet specifications

Datasheet's name MCH3478
File size 286.283 KB
File type pdf
Number of pages 5

Download Datasheet MCH3478

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 30V
  • Current - Continuous Drain (Id) @ 25°C: 2A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 1.8V, 4.5V
  • Rds On (Max) @ Id, Vgs: 165mOhm @ 1A, 4.5V
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: 1.7nC @ 4.5V
  • Vgs (Max): ±12V
  • Input Capacitance (Ciss) (Max) @ Vds: 130pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 800mW (Ta)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 3-MCPH
  • Package / Case: 3-SMD, Flat Lead
  • Base Part Number: MCH34
  • detail: N-Channel 30V 2A (Ta) 800mW (Ta) Surface Mount 3-MCPH
