AT-41500-GP4 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Tray
- Part Status: Obsolete
- Transistor Type: NPN
- Voltage - Collector Emitter Breakdown (Max): 12V
- Frequency - Transition: 8GHz
- Noise Figure (dB Typ @ f): 1.4dB ~ 3dB @ 1GHz ~ 4GHz
- Gain: 8dB ~ 17dB
- Power - Max: 500mW
- DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 10mA, 8V
- Current - Collector (Ic) (Max): 60mA
- Operating Temperature: 200°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: Die
- Supplier Device Package: Die
- detail: RF Transistor NPN 12V 60mA 8GHz 500mW Surface Mount Die
