ACMD-7602-BLKG Datasheet

ACMD-7602

Datasheet specifications

Datasheet's name ACMD-7602
File size 736.296 KB
File type pdf
Number of pages 12

Download Datasheet ACMD-7602

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Bulk
  • Part Status: Obsolete
  • Type: Duplexer
  • Frequency Bands (Low / High): 1.92GHz ~ 1.98GHz / 2.11GHz ~ 2.17GHz
  • Low Band Attenuation (min / max dB): 53.00dB / -
  • High Band Attenuation (min / max dB): 41.00dB / -
  • Return Loss (Low Band / High Band): 20.0dB / 16.0dB
  • Mounting Type: Surface Mount
  • Package / Case: 3-CSP
  • detail: RF Diplexor Duplexer 1.92GHz ~ 1.98GHz / 2.11GHz ~ 2.17GHz 3-CSP
