FDC6304P دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDC6304P	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: 2 P-Channel (Dual)
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 25V
Current - Continuous Drain (Id) @ 25°C: 460mA
Rds On (Max) @ Id, Vgs: 1.1Ohm @ 500mA, 4.5V
Vgs(th) (Max) @ Id: 1.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 1.5nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds: 62pF @ 10V
Power - Max: 700mW
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: SOT-23-6 Thin, TSOT-23-6
Supplier Device Package: SuperSOT™-6
Base Part Number: FDC6304
detail: Mosfet Array 2 P-Channel (Dual) 25V 460mA 700mW Surface Mount SuperSOT™-6
