NCV8715SQ33T2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCV8715SQ33T2G
|
|
حجم فایل
|
71.857
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV8715SQ33T2G
-
Output Current:
50mA
-
Output Voltage:
3.3V
-
Dropout Voltage:
0.35V@(50mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
24V
-
Operating Temperature:
-40°C~+125°C@(Ta)
-
Quiescent Current (Ground Current):
5.8uA
-
Power Supply Rejection Ratio (PSRR):
60dB@(100kHz)
-
Package:
SC-88A-5
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
24V
-
Voltage - Output (Min/Fixed):
3.3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.35V @ 50mA
-
Current - Output:
50mA
-
Current - Quiescent (Iq):
5.8µA
-
PSRR:
60dB (100kHz)
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
5-TSSOP, SC-70-5, SOT-353
-
Supplier Device Package:
SC-88A (SC-70-5/SOT-353)
-
Base Part Number:
NCV8715
-
detail:
Linear Voltage Regulator IC 1 Output 50mA SC-88A (SC-70-5/SOT-353)
