HDSP-301A 数据手册
数据手册规格
|
数据手册名称
|
HDSP-301x,303x,561x,563x
|
|
文件大小
|
166.331
千字节
|
|
文件类型
|
pdf
|
|
页数
|
9
|
技术规格
-
Manufacturer:
Broadcom Limited
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
Number of Characters:
1
-
Size / Dimension:
0.504" H x 0.382" W x 0.276" D (12.80mm x 9.70mm x 7.00mm)
-
Digit/Alpha Size:
0.40" (10.16mm)
-
Display Type:
7-Segment
-
Common Pin:
Common Anode
-
Color:
Red
-
Voltage - Forward (Vf) (Typ):
1.8V
-
Current - Test:
20mA
-
Millicandela Rating:
0.45mcd
-
Wavelength - Peak:
660nm
-
Power Dissipation (Max):
37mW
-
Package / Case:
10-DIP (0.300", 7.62mm)
-
detail:
Display Modules - LED Character and Numeric Red 7-Segment 1 Character Common Anode 1.8V 20mA 0.504" H x 0.382" W x 0.276" D (12.80mm x 9.70mm x 7.00mm) 10-DIP (0.300", 7.62mm)
