NCV5661MN33T2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCV5661MN33T2G
|
|
حجم فایل
|
85.751
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV5661MN33T2G
-
Package:
SOP-16
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
9V
-
Voltage - Output (Min/Fixed):
3.3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
1.3V @ 1A
-
Current - Output:
1A
-
Current - Quiescent (Iq):
3mA
-
PSRR:
70dB ~ 65dB (120Hz ~ 1kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
6-VDFN Exposed Pad
-
Supplier Device Package:
6-DFN (3x3)
-
Base Part Number:
NCV5661
-
detail:
Linear Voltage Regulator IC 1 Output 1A 6-DFN (3x3)
