دیتاشیت FQD3N60CTM-WS

FQD3N60CTM_WS

مشخصات دیتاشیت

نام دیتاشیت FQD3N60CTM_WS
حجم فایل 977.842 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت FQD3N60CTM_WS

FQD3N60CTM_WS Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: QFET®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 600V
  • Current - Continuous Drain (Id) @ 25°C: 2.4A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 3.4Ohm @ 1.2A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 14nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 565pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 50W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: D-Pak
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Base Part Number: FQD3
  • detail: N-Channel 600V 2.4A (Tc) 50W (Tc) Surface Mount D-Pak
