دیتاشیت SB80W06T-TL-H

SB80W06T

مشخصات دیتاشیت

نام دیتاشیت SB80W06T
حجم فایل 346.486 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت SB80W06T

SB80W06T Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Not For New Designs
  • Diode Configuration: 1 Pair Common Cathode
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 60V
  • Current - Average Rectified (Io) (per Diode): 4A
  • Voltage - Forward (Vf) (Max) @ If: 600mV @ 3A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 100µA @ 30V
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: TP-FA
  • Base Part Number: SB80
  • detail: Diode Array 1 Pair Common Cathode Schottky 60V 4A Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63
