دیتاشیت NUF8410MNT4G
مشخصات دیتاشیت
| نام دیتاشیت |
NUF8410MN
|
| حجم فایل |
112.829
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Category:
Bead/Filter/EMI Optimization/EMI Filters (LC, RC Networks)
-
Datasheet:
onsemi NUF8410MNT4G
-
Package:
DFN-16(1.6x4)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Low Pass
-
Filter Order:
2nd
-
Technology:
RC (Pi)
-
Number of Channels:
8
-
Center / Cutoff Frequency:
250MHz (Cutoff)
-
Attenuation Value:
-20dB @ 800MHz ~ 3GHz
-
Resistance - Channel (Ohms):
100
-
Values:
R = 100Ohms, C = 8.5pF
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
16-VFDFN Exposed Pad
-
Size / Dimension:
0.157" L x 0.063" W (4.00mm x 1.60mm)
-
Height:
0.039" (1.00mm)
-
Base Part Number:
NUF8410
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 8 Channel R = 100Ohms, C = 8.5pF 16-VFDFN Exposed Pad
