NCP1230D165R2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP1230D165R2G
|
|
حجم فایل
|
98.284
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
24
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Flyback
-
Datasheet:
onsemi NCP1230D165R2G
-
Duty Cycle:
80%
-
Supply Voltage:
7.7V~18V
-
Output Isolation:
Isolation
-
Switching Frequency:
65kHz
-
Operating Temperature:
-40°C~+125°C@(Tj)
-
Package:
SOP-7
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Not For New Designs
-
Internal Switch(s):
No
-
Voltage - Breakdown:
-
-
Voltage - Start Up:
12.6V
-
Voltage - Supply (Vcc/Vdd):
7.7V ~ 18V
-
Frequency - Switching:
65kHz
-
Fault Protection:
Current Limiting, Over Temperature, Over Voltage, Short Circuit
-
Control Features:
-
-
Package / Case:
8-SOIC (0.154", 3.90mm Width), 7 Leads
-
Supplier Device Package:
7-SOIC
-
Mounting Type:
Surface Mount
-
Base Part Number:
NCP1230
-
detail:
Converter Offline Flyback Topology 65kHz 7-SOIC
