دیتاشیت NJVNJD2873T4G-VF01
مشخصات دیتاشیت
| نام دیتاشیت | NJD2873 |
|---|---|
| حجم فایل | 68.157 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت NJD2873 |
NJD2873 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: onsemi NJVNJD2873T4G-VF01
- Transistor Type: NPN
- Operating Temperature: -65°C~+175°C@(Tj)
- Collector Current (Ic): 2A
- Power Dissipation (Pd): 1.68W
- Transition Frequency (fT): 65MHz
- DC Current Gain (hFE@Ic,Vce): 120@500mA,2V
- Collector Cut-Off Current (Icbo): 100nA
- Collector-Emitter Breakdown Voltage (Vceo): 50V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 300mV@50mA,1A
- Package: DPAK-3
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101
- Packaging: Cut Tape (CT)
- Part Status: Active
- Current - Collector (Ic) (Max): 2A
- Voltage - Collector Emitter Breakdown (Max): 50V
- Vce Saturation (Max) @ Ib, Ic: 300mV @ 50mA, 1A
- Current - Collector Cutoff (Max): 100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 120 @ 500mA, 2V
- Power - Max: 1.68W
- Frequency - Transition: 65MHz
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Base Part Number: NJVNJD287
- detail: Bipolar (BJT) Transistor NPN 50V 2A 65MHz 1.68W Surface Mount DPAK
