- دیتاشیت MBR1240MFST1G
MBR1240MFST1G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MBR1240MFST1G |
|---|---|
| حجم فایل | 95.466 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت MBR1240MFST1G |
دانلود دیتاشیت |
|---|
سایر مستندات
MBR1240MFS, NRVB1240MFS 5 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi MBR1240MFST1G
- Diode Configuration: Single
- Reverse Voltage (Vr): 40V
- Forward Voltage (Vf@If): 530mV@12A
- Reverse Leakage Current (Ir): 80uA@40V
- Average Rectified Current (Io): 12A
- Package: SO-8FL
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40V
- Current - Average Rectified (Io): 12A
- Voltage - Forward (Vf) (Max) @ If: 680mV @ 12A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 500µA @ 40V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: 8-PowerTDFN, 5 Leads
- Supplier Device Package: 5-DFN (5x6) (8-SOFL)
- Operating Temperature - Junction: -55°C ~ 150°C
- Base Part Number: MBR1240
- detail: Diode Schottky 40V 12A Surface Mount 5-DFN (5x6) (8-SOFL)
