دیتاشیت NCV4275CDT50RKG
مشخصات دیتاشیت
| نام دیتاشیت |
NCV4275C
|
| حجم فایل |
157.795
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
15
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV4275CDT50RKG
-
Output Current:
450mA
-
Output Voltage:
5V
-
Dropout Voltage:
0.5V@(300mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
42V
-
Operating Temperature:
-40°C~+150°C
-
Quiescent Current (Ground Current):
150uA
-
Power Supply Rejection Ratio (PSRR):
60dB@(100Hz)
-
Package:
DPAK-5
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
42V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.5V @ 300mA
-
Current - Output:
450mA
-
Current - Quiescent (Iq):
150µA
-
Current - Supply (Max):
35mA
-
PSRR:
60dB (100Hz)
-
Control Features:
Reset
-
Protection Features:
Over Temperature, Reverse Polarity, Short Circuit
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-5, DPak (4 Leads + Tab), TO-252AD
-
Supplier Device Package:
DPAK-5
-
Base Part Number:
NCV4275
-
detail:
Linear Voltage Regulator IC 1 Output 450mA DPAK-5
