دیتاشیت L6388ED013TR

L6388E

مشخصات دیتاشیت

نام دیتاشیت L6388E
حجم فایل 424.643 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت L6388E

L6388E Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: STMicroelectronics L6388ED013TR
  • Fall Time: 40ns
  • Load Type: IGBT;MOSFET
  • Rise Time: 70ns
  • Supply Voltage: 17V
  • Number of Drivers: 2
  • Driven Configuration: Half Bridge
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Peak Output Current(sink): 650mA
  • Peak Output Current(source): 400mA
  • Package: SOP-8
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Channel Type: Independent
  • Gate Type: IGBT, N-Channel MOSFET
  • Voltage - Supply: 17V (Max)
  • Logic Voltage - VIL, VIH: 1.1V, 1.8V
  • Current - Peak Output (Source, Sink): 400mA, 650mA
  • Input Type: Inverting
  • High Side Voltage - Max (Bootstrap): 600V
  • Rise / Fall Time (Typ): 70ns, 40ns
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SO
  • Base Part Number: L6388
  • detail: Half-Bridge Gate Driver IC Inverting 8-SO
