AT-42000-GP4 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Tray
- Part Status: Obsolete
- Transistor Type: NPN
- Voltage - Collector Emitter Breakdown (Max): 12V
- Frequency - Transition: 9GHz
- Noise Figure (dB Typ @ f): 1.9dB ~ 3dB @ 2GHz ~ 4GHz
- Gain: 10.5dB ~ 14dB
- Power - Max: 600mW
- DC Current Gain (hFE) (Min) @ Ic, Vce: 30 @ 35mA, 8V
- Current - Collector (Ic) (Max): 80mA
- Operating Temperature: 200°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: Die
- Supplier Device Package: Chip
- detail: RF Transistor NPN 12V 80mA 9GHz 600mW Surface Mount Chip
