دیتاشیت FGD3440G2-F085

FGD3440G2_F085

مشخصات دیتاشیت

نام دیتاشیت FGD3440G2_F085
حجم فایل 461.699 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت FGD3440G2_F085

FGD3440G2_F085 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: EcoSPARK®
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • IGBT Type: -
  • Voltage - Collector Emitter Breakdown (Max): 400V
  • Current - Collector (Ic) (Max): 26.9A
  • Vce(on) (Max) @ Vge, Ic: 1.2V @ 4V, 6A
  • Power - Max: 166W
  • Switching Energy: -
  • Input Type: Logic
  • Gate Charge: 24nC
  • Td (on/off) @ 25°C: -/5.3µs
  • Test Condition: 300V, 6.5A, 1kOhm, 5V
  • Operating Temperature: -40°C ~ 175°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: TO-252AA
  • Base Part Number: FGD3
  • detail: IGBT 400V 26.9A 166W Surface Mount TO-252AA
