NCV5662DSADJR4G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCV5662DSADJR4G
|
|
حجم فایل
|
86.985
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV5662DSADJR4G
-
Output Type:
Adjustable
-
Output Current:
2A
-
Output Voltage:
0.9V~7.7V
-
Dropout Voltage:
1.3V@(2A)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
9V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
3mA
-
Power Supply Rejection Ratio (PSRR):
70dB@(120Hz),65dB@(1kHz)
-
Package:
D2PAK
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
9V
-
Voltage - Output (Min/Fixed):
0.9V
-
Voltage - Output (Max):
7.7V
-
Voltage Dropout (Max):
1.3V @ 2A
-
Current - Output:
2A
-
Current - Quiescent (Iq):
3mA
-
PSRR:
70dB ~ 65dB (120Hz ~ 1kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Supplier Device Package:
D2PAK-5
-
Base Part Number:
NCV5662
-
detail:
Linear Voltage Regulator IC 1 Output 2A D2PAK-5
