دیتاشیت HSMF-C168

HSMF-C16x

مشخصات دیتاشیت

نام دیتاشیت HSMF-C16x
حجم فایل 120.204 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت HSMF-C16x

HSMF-C16x Datasheet

مشخصات

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Color: Blue, Green
  • Configuration: Independent
  • Lens Color: White
  • Lens Transparency: Diffused
  • Millicandela Rating: 10mcd Blue, 45mcd Green
  • Lens Style: Rectangle with Flat Top
  • Lens Size: 1.60mm x 0.80mm
  • Voltage - Forward (Vf) (Typ): 3.4V Blue, 3.4V Green
  • Current - Test: 20mA Blue, 20mA Green
  • Viewing Angle: 120°
  • Mounting Type: Surface Mount
  • Wavelength - Dominant: 470nm Blue, 525nm Green
  • Wavelength - Peak: 468nm Blue, 523nm Green
  • Features: -
  • Package / Case: 0603 (1608 Metric)
  • Size / Dimension: 1.60mm L x 0.80mm W
  • Height (Max): 0.50mm
  • Base Part Number: HSMF-C16
  • detail: Blue, Green 470nm Blue, 525nm Green LED Indication - Discrete 3.4V Blue, 3.4V Green 0603 (1608 Metric)
