دیتاشیت FQPF7P20

FQPF7P20

مشخصات دیتاشیت

نام دیتاشیت FQPF7P20
حجم فایل 1162.952 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت FQPF7P20

FQPF7P20 Datasheet

مشخصات

  • RoHS: true
  • Type: P Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi FQPF7P20
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 45W
  • Total Gate Charge (Qg@Vgs): 25nC@10V
  • Drain Source Voltage (Vdss): 200V
  • Input Capacitance (Ciss@Vds): 770pF@25V
  • Continuous Drain Current (Id): 5.2A
  • Gate Threshold Voltage (Vgs(th)@Id): 5V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 690mΩ@2.6A,10V
  • Package: TO-220
  • Manufacturer: onsemi
  • Series: QFET®
  • Packaging: Tube
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 200V
  • Current - Continuous Drain (Id) @ 25°C: 5.2A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 690mOhm @ 2.6A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 25nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 770pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 45W (Tc)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-220F
  • Package / Case: TO-220-3 Full Pack
  • Base Part Number: FQPF7
  • detail: P-Channel 200V 5.2A (Tc) 45W (Tc) Through Hole TO-220F
