NCP7815TG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCP7815TG
|
|
حجم فایل
|
77.337
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP7815TG
-
Package:
TO-220
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
35V
-
Voltage - Output (Min/Fixed):
15V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
2V @ 1A (Typ)
-
Current - Output:
1A
-
Current - Quiescent (Iq):
8mA
-
PSRR:
70dB (120Hz)
-
Control Features:
-
-
Protection Features:
Over Temperature, Short Circuit
-
Operating Temperature:
0°C ~ 125°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220-3
-
Base Part Number:
NCP7815
-
detail:
Linear Voltage Regulator IC 1 Output 1A TO-220-3
