NCP3901FCCT1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NCP3901FCCT1G	دانلود دیتاشیت

NCP3901 12 pages

RoHS: true
Category: Power Supply Chip/AC-DC Controllers & Regulators
Features: Thermal Protection(OPT);Overvoltage protection(OVP);Undervoltage Protection(UVP)
Datasheet: onsemi NCP3901FCCT1G
Output Current: 3A
Supply Voltage: 0V~28V
Operating Temperature: -40°C~+125°C@(Tj)
Package: UFBGA-4
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Switch Type: USB Switch
Number of Outputs: 1
Ratio - Input:Output: 2:1
Output Configuration: High Side or Low Side
Output Type: N-Channel
Interface: On/Off
Voltage - Load: 0V ~ 5.5V
Voltage - Supply (Vcc/Vdd): 0V ~ 28V
Current - Output (Max): 3A
Rds On (Typ): 50mOhm
Input Type: Differential
Fault Protection: Over Temperature, Over Voltage, UVLO
Mounting Type: Surface Mount
Supplier Device Package: 28-WLCSP
Package / Case: 28-UFBGA, WLCSP
Base Part Number: NCP390
detail: Power Switch/Driver 2:1 N-Channel 3A 28-WLCSP
