دیتاشیت NBRD5H100T4G-VF01
مشخصات دیتاشیت
| نام دیتاشیت | MBRD5H100, NBRD5H100 |
|---|---|
| حجم فایل | 136.279 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت MBRD5H100, NBRD5H100 |
MBRD5H100, NBRD5H100 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi NBRD5H100T4G-VF01
- Reverse Voltage (Vr): 100V
- Forward Voltage (Vf@If): 710mV@5A
- Reverse Leakage Current (Ir): 3.5uA@100V
- Average Rectified Current (Io): 5A
- Package: TO-252
- Manufacturer: onsemi
- Series: Automotive, AEC-Q101, SWITCHMODE™
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 100V
- Current - Average Rectified (Io): 5A
- Voltage - Forward (Vf) (Max) @ If: 710mV @ 5A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 3.5µA @ 100V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Operating Temperature - Junction: -65°C ~ 175°C
- Base Part Number: NBRD5H
- detail: Diode Schottky 100V 5A Surface Mount DPAK
