ASMC-QxB2-Tzzzz دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ASMC-QxB2-Tzzzz
|
|
حجم فایل
|
137.156
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
Manufacturer:
Broadcom Limited
-
Series:
Envisium™
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Color:
Red
-
Wavelength:
618nm (611nm ~ 625nm)
-
Current - Test:
150mA
-
Voltage - Forward (Vf) (Typ):
2.64V
-
Lumens/Watt @ Current - Test:
23 lm/W
-
Current - Max:
300mA
-
Flux @ Current/Temperature - Test:
9lm (7lm ~ 12lm)
-
Temperature - Test:
25°C
-
Viewing Angle:
120°
-
Mounting Type:
Surface Mount
-
Package / Case:
4-PLCC
-
Supplier Device Package:
4-PLCC
-
Size / Dimension:
0.126" L x 0.110" W (3.20mm x 2.80mm)
-
Height - Seated (Max):
0.083" (2.10mm)
-
Thermal Resistance of Package:
60°C/W
-
Base Part Number:
ASMC-Q*B2
-
detail:
LED Lighting Color Envisium™ Red 618nm (611nm ~ 625nm) 4-PLCC
