FDMF4061 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDMF4061	دانلود دیتاشیت

FDMF4061 32 pages

RoHS: true
Category: Power Supply Chip/Gate Drive ICs
Datasheet: onsemi FDMF4061
Load Type: MOSFET
Supply Voltage: 10V~20V
Driven Configuration: Half Bridge
Operating Temperature: -40°C~+125°C@(Tj)
Package: -
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Half Bridge
Applications: DC Motors, DC-DC Converters
Interface: PWM
Technology: Power MOSFET
Rds On (Typ): 2.4mOhm LS + HS
Current - Output / Channel: 25A
Current - Peak Output: -
Voltage - Supply: 10V ~ 20V
Voltage - Load: 3V ~ 50V
Features: Bootstrap Circuit
Fault Protection: UVLO
Mounting Type: Surface Mount
Package / Case: 36-PowerWFQFN
Supplier Device Package: 36-PQFN (7.5x6)
Base Part Number: FDMF40
detail: Half Bridge Driver DC Motors, DC-DC Converters Power MOSFET 36-PQFN (7.5x6)
