دیتاشیت LV8728MR-AH

LV8728MR

مشخصات دیتاشیت

نام دیتاشیت LV8728MR
حجم فایل 828.179 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت LV8728MR

LV8728MR Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Motor Type - Stepper: Bipolar
  • Motor Type - AC, DC: -
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (4)
  • Interface: -
  • Technology: BiCDMOS
  • Step Resolution: 1 ~ 1/128
  • Applications: Printer
  • Current - Output: 2A
  • Voltage - Supply: 0V ~ 5V
  • Voltage - Load: 9V ~ 32V
  • Operating Temperature: -30°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 30-SOP (0.311", 7.90mm Width) Exposed Pad
  • Supplier Device Package: 30-SOIC/MFP30KR
  • Base Part Number: LV872
  • detail: Bipolar Motor Driver BiCDMOS 30-SOIC/MFP30KR
