MCH6203-TL-E دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MCH6203-TL-E
|
|
حجم فایل
|
49.426
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi MCH6203-TL-E
-
Transistor Type:
NPN
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
1A
-
Power Dissipation (Pd):
1W
-
Transition Frequency (fT):
420MHz
-
DC Current Gain (hFE@Ic,Vce):
200@100mA,2V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
50V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
130mV@500mA,10mA
-
Package:
MCPH-6
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
1A
-
Voltage - Collector Emitter Breakdown (Max):
50V
-
Vce Saturation (Max) @ Ib, Ic:
430mV @ 10mA, 500mA
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
200 @ 100mA, 2V
-
Power - Max:
1W
-
Frequency - Transition:
420MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
6-SMD, Flat Leads
-
Supplier Device Package:
6-MCPH
-
Base Part Number:
MCH62
-
detail:
Bipolar (BJT) Transistor NPN 50V 1A 420MHz 1W Surface Mount 6-MCPH
