NCV8160AMX180TBG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NCV8160AMX180TBG
|
|
حجم فایل
|
74.106
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV8160AMX180TBG
-
Package:
DFN-4(1x1)
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
1.8V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.25V @ 250mA
-
Current - Output:
250mA
-
Current - Quiescent (Iq):
23µA
-
PSRR:
91dB ~ 48dB (100Hz ~ 100kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
4-XDFN Exposed Pad
-
Supplier Device Package:
4-XDFN (1x1)
-
Base Part Number:
NCV8160
-
detail:
Linear Voltage Regulator IC 1 Output 250mA 4-XDFN (1x1)
