- دیتاشیت TL431IDMR2G
TL431IDMR2G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TL431IDMR2G |
|---|---|
| حجم فایل | 88.18 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت TL431IDMR2G |
دانلود دیتاشیت |
|---|
سایر مستندات
TL431(A, B), NCV431(A, B), SCV431A 18 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: onsemi TL431IDMR2G
- Tolerance: ±2.2%
- Output Type: Adjustable
- Input Voltage: -
- Output Current: 100mA
- Reference Type: parallel connection
- Supply Current: -
- Noise - 10Hz to 10kHz: -
- Operating Temperature: -40°C~+85°C@(Ta)
- Noise - 1/10Hz to 10Hz: -
- Temperature Coefficient: 50ppm/°C
- Package: Micro-8
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Output (Min/Fixed): 2.495V
- Voltage - Output (Max): 36V
- Current - Output: 100mA
- Noise - 0.1Hz to 10Hz: -
- Voltage - Input: -
- Current - Supply: -
- Current - Cathode: 1mA
- Mounting Type: Surface Mount
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: Micro8™
- Base Part Number: TL431
- detail: Shunt Voltage Reference IC 36V ±2.2% Micro8™
