NCP154MX180280TAG دیتاشیت

NCP154MX180280TAG

مشخصات دیتاشیت

نام دیتاشیت NCP154MX180280TAG
حجم فایل 75.39 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت NCP154MX180280TAG

دانلود دیتاشیت

سایر مستندات

NCP154 18 pages

مشخصات فنی

  • RoHS: true
  • Feature: Overcurrent Protection;Thermal Protection
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCP154MX180280TAG
  • Output Current: 300mA
  • Output Voltage: 1.8V;2.8V
  • Dropout Voltage: 0.39V@(300mA);0.27V@(300mA)
  • Output Polarity: positive
  • Number of Outputs: 2
  • Maximum Input Voltage: 5.25V
  • Operating Temperature: -40°C~+85°C
  • Quiescent Current (Ground Current): 100uA
  • Power Supply Rejection Ratio (PSRR): 75dB@(1kHz)
  • Package: DFN-8(1.2x1.6)
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 2
  • Voltage - Input (Max): 5.25V
  • Voltage - Output (Min/Fixed): 1.8V, 2.8V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.39V @ 300mA, 0.27V @ 300mA
  • Current - Output: 300mA, 300mA
  • Current - Quiescent (Iq): 100µA
  • Current - Supply (Max): 200µA
  • PSRR: 75dB (1kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: 8-XFDFN Exposed Pad
  • Supplier Device Package: 8-XDFN (1.6x1.2)
  • Base Part Number: NCP154
  • detail: Linear Voltage Regulator IC 2 Output 300mA, 300mA 8-XDFN (1.6x1.2)
