دیتاشیت ASMT-QTB2-0A002

مشخصات دیتاشیت

دانلود دیتاشیت ASMT-QTB2-zzzzz	ASMT-QTB2-zzzzz Datasheet

Manufacturer: Broadcom Limited
Series: -
Packaging: Tape & Reel (TR)
Part Status: Obsolete
Color: Red, Green, Blue (RGB)
Configuration: Common Anode
Lens Color: Colorless
Lens Transparency: Clear
Millicandela Rating: 505mcd Red, 1015mcd Green, 325mcd Blue
Lens Style: Round with Flat Top
Lens Size: 2.90mm Dia
Voltage - Forward (Vf) (Typ): 2.06V Red, 3.32V Green, 3.32V Blue
Current - Test: 20mA Red, 20mA Green, 20mA Blue
Viewing Angle: 120°
Mounting Type: Surface Mount
Wavelength - Dominant: 628nm Red, 526nm Green, 472nm Blue
Wavelength - Peak: 639nm Red, 519nm Green, 467nm Blue
Features: -
Package / Case: 4-SMD, No Lead
Supplier Device Package: 4-PLCC
Size / Dimension: 3.60mm L x 3.20mm W
Height (Max): 2.20mm
Base Part Number: ASMT-Q*B2
detail: Red, Green, Blue (RGB) 628nm Red, 526nm Green, 472nm Blue LED Indication - Discrete 2.06V Red, 3.32V Green, 3.32V Blue 4-SMD, No Lead
