دیتاشیت ASMT-QTC0-0AA02
مشخصات دیتاشیت
نام دیتاشیت | ASMT-QTC0-0AA02 |
---|---|
حجم فایل | 160.744 کیلوبایت |
نوع فایل | |
تعداد صفحات | 10 |
دانلود دیتاشیت ASMT-QTC0-0AA02 |
ASMT-QTC0-0AA02 Datasheet |
---|
مشخصات
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Color: Red, Green, Blue (RGB)
- Configuration: Common Anode
- Lens Color: Colorless
- Lens Transparency: Clear
- Millicandela Rating: 315mcd Red, 470mcd Green, 140mcd Blue
- Lens Style: Round with Flat Top
- Lens Size: 2.90mm Dia
- Voltage - Forward (Vf) (Typ): 2.1V Red, 3.2V Green, 3.2V Blue
- Current - Test: 20mA Red, 20mA Green, 20mA Blue
- Viewing Angle: 115°
- Mounting Type: Surface Mount
- Wavelength - Dominant: 621nm Red, 528nm Green, 470nm Blue
- Wavelength - Peak: 629nm Red, 521nm Green, 465nm Blue
- Features: -
- Package / Case: 4-SMD, J-Lead
- Supplier Device Package: 4-PLCC
- Size / Dimension: 3.40mm L x 3.20mm W
- Height (Max): 2.20mm
- Base Part Number: ASMT-QTC0
- detail: Red, Green, Blue (RGB) 621nm Red, 528nm Green, 470nm Blue LED Indication - Discrete 2.1V Red, 3.2V Green, 3.2V Blue 4-SMD, J-Lead
