دیتاشیت ASMT-YTB0-0AA02

مشخصات دیتاشیت

دانلود دیتاشیت ASMT-YTB0-0zzzz	ASMT-YTB0-0zzzz Datasheet

Manufacturer: Broadcom Limited
Series: -
Packaging: Cut Tape (CT)
Part Status: Obsolete
Color: Red, Green, Blue (RGB)
Configuration: Independent
Lens Color: Colorless
Lens Transparency: Clear
Millicandela Rating: 648mcd Red, 1243mcd Green, 238mcd Blue
Lens Style: Rectangle with Flat Top
Lens Size: 3.40mm x 3.90mm
Voltage - Forward (Vf) (Typ): 2.1V Red, 3.2V Green, 3.2V Blue
Current - Test: 20mA Red, 20mA Green, 20mA Blue
Viewing Angle: 115°
Mounting Type: Surface Mount
Wavelength - Dominant: 621nm Red, 528nm Green, 470nm Blue
Wavelength - Peak: 629nm Red, 521nm Green, 465nm Blue
Features: -
Package / Case: 6-SMD, J-Lead
Supplier Device Package: 6-PLCC
Size / Dimension: 4.40mm L x 4.00mm W
Height (Max): 3.70mm
Base Part Number: ASMT-YTB0
detail: Red, Green, Blue (RGB) 621nm Red, 528nm Green, 470nm Blue LED Indication - Discrete 2.1V Red, 3.2V Green, 3.2V Blue 6-SMD, J-Lead
