HSMW-CL25 Datasheet
Datasheet specifications
| Datasheet's name | HSMW-CL25 |
|---|---|
| File size | 166.909 KB |
| File type | |
| Number of pages | 6 |
Download Datasheet HSMW-CL25 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Broadcom Limited
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Color: White
- Configuration: Standard
- Lens Color: White
- Lens Transparency: Diffused
- Millicandela Rating: 70mcd
- Lens Style: Rectangle with Flat Top
- Lens Size: 1.10mm x 0.80mm
- Voltage - Forward (Vf) (Typ): 2.85V
- Current - Test: 5mA
- Viewing Angle: 120°
- Mounting Type: Surface Mount
- Wavelength - Dominant: -
- Wavelength - Peak: -
- Features: -
- Package / Case: 0603 (1608 Metric)
- Supplier Device Package: Chip LED
- Size / Dimension: 1.60mm L x 0.80mm W
- Height (Max): 0.30mm
- Base Part Number: HSMW-CL25
- detail: White LED Indication - Discrete 2.85V 0603 (1608 Metric)
