NL17SG08DFT2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NL17SG08DFT2G
|
|
حجم فایل
|
77.628
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Series:
-
-
Category:
Logic ICs/Gates
-
Datasheet:
onsemi NL17SG08DFT2G
-
Sink Current:
8mA
-
Source Current:
8mA
-
Supply Voltage:
0.9V~3.6V
-
Logic Gate Type:
And
-
Number of Channels:
1
-
Low Level Range (VIL):
0.7V~0.8V
-
Operating Temperature:
-55°C~+125°C
-
High Level Range (VIH):
1.7V~2V
-
Propagation Delay Time:
4.9ns@3.3V,30pF
-
Quiescent Current (Max):
500nA
-
Package:
SC-88A-5
-
Manufacturer:
onsemi
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Logic Type:
AND Gate
-
Number of Circuits:
1
-
Number of Inputs:
2
-
Features:
-
-
Voltage - Supply:
0.9V ~ 3.6V
-
Current - Quiescent (Max):
500nA
-
Current - Output High, Low:
8mA, 8mA
-
Logic Level - Low:
0.7V ~ 0.8V
-
Logic Level - High:
1.7V ~ 2V
-
Max Propagation Delay @ V, Max CL:
4.9ns @ 3.3V, 30pF
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
SC-88A (SC-70-5/SOT-353)
-
Package / Case:
5-TSSOP, SC-70-5, SOT-353
-
Base Part Number:
NL17S
-
detail:
AND Gate IC 1 Channel SC-88A (SC-70-5/SOT-353)
