HSME-C177 Datasheet

HSME-Cxxx

Datasheet specifications

Datasheet's name HSME-Cxxx
File size 201.632 KB
File type pdf
Number of pages 12

Download Datasheet HSME-Cxxx

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Broadcom Limited
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Color: Green
  • Configuration: Standard
  • Lens Color: White
  • Lens Transparency: Diffused
  • Millicandela Rating: 50mcd
  • Lens Style: Rectangle with Flat Top
  • Lens Size: 2.00mm x 1.25mm
  • Voltage - Forward (Vf) (Typ): 2.1V
  • Current - Test: 20mA
  • Viewing Angle: 130°
  • Mounting Type: Surface Mount
  • Wavelength - Dominant: 572nm
  • Wavelength - Peak: 570nm
  • Features: -
  • Package / Case: 0805 (2012 Metric)
  • Supplier Device Package: Chip LED
  • Size / Dimension: 2.00mm L x 1.25mm W
  • Height (Max): 0.40mm
  • Base Part Number: HSME-C177
  • detail: Green 572nm LED Indication - Discrete 2.1V 0805 (2012 Metric)
