دیتاشیت EGP10D
مشخصات دیتاشیت
| نام دیتاشیت | EGP10A - EGP10K |
|---|---|
| حجم فایل | 273.635 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت EGP10A - EGP10K |
EGP10A - EGP10K Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Diodes - General Purpose
- Datasheet: onsemi EGP10D
- Diode Configuration: -
- Reverse Voltage (Vr): 200V
- Forward Voltage (Vf@If): 950mV@1A
- Reverse Leakage Current: 5uA@200V
- Average Rectified Current (Io): 1A
- Package: DO-41
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 200V
- Current - Average Rectified (Io): 1A
- Voltage - Forward (Vf) (Max) @ If: 950mV @ 1A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 50ns
- Current - Reverse Leakage @ Vr: 5µA @ 200V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: DO-204AL, DO-41, Axial
- Supplier Device Package: DO-204AL (DO-41)
- Operating Temperature - Junction: -65°C ~ 150°C
- Base Part Number: EGP10
- detail: Diode Standard 200V 1A Through Hole DO-204AL (DO-41)
