NCP136AFCT110T2G دیتاشیت

NCP136AFCT110T2G

مشخصات دیتاشیت

نام دیتاشیت NCP136AFCT110T2G
حجم فایل 77.672 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

دانلود دیتاشیت NCP136AFCT110T2G

دانلود دیتاشیت

سایر مستندات

NCP136 13 pages

مشخصات فنی

  • RoHS: true
  • Feature: enable
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCP136AFCT110T2G
  • Output Type: Fixed
  • Output Current: 700mA
  • Output Voltage: 1.1V
  • Dropout Voltage: 60mV@(700mA)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+85°C@(Tj)
  • Quiescent Current (Ground Current): 110uA
  • Power Supply Rejection Ratio (PSRR): 75dB@(1kHz)
  • Package: WLCSP-6
  • Manufacturer: onsemi
  • Series: -
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 1.1V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.06V @ 700mA
  • Current - Output: 700mA
  • Current - Quiescent (Iq): 110µA
  • PSRR: 75dB (1kHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: 6-XFBGA, WLCSP
  • Supplier Device Package: 6-WLCSP (1.4x0.8)
  • Base Part Number: NCP136
  • detail: Linear Voltage Regulator IC 1 Output 700mA 6-WLCSP (1.4x0.8)
