دیتاشیت NTTFS010N10MCLTAG

مشخصات دیتاشیت

دانلود دیتاشیت NTTFS010N10MCL	NTTFS010N10MCL Datasheet

Manufacturer: ON Semiconductor
Series: PowerTrench®
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: N-Channel
Technology: MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss): 100V
Current - Continuous Drain (Id) @ 25°C: 10.7A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Rds On (Max) @ Id, Vgs: 10.6mOhm @ 15A, 10V
Vgs(th) (Max) @ Id: 3V @ 85µA
Gate Charge (Qg) (Max) @ Vgs: 30nC @ 10V
Vgs (Max): ±20V
Input Capacitance (Ciss) (Max) @ Vds: 2150pF @ 50V
Power Dissipation (Max): 2.3W (Ta),52W (Tc)
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: 8-WDFN (3.3x3.3)
Package / Case: 8-PowerWDFN
Base Part Number: NTTFS010
detail: N-Channel 100V 10.7A (Ta), 50A (Tc) 2.3W (Ta),52W (Tc) Surface Mount 8-WDFN (3.3x3.3)
